MILTECH 9128 Managed Board Level 24 Port Router/Switch with 4 x 10G Fiber ports

Key Features
Product Type:Embedded ethernet board-level switch
24 x 1G Copper
4 x 10G Fiber
Designed to Meet:MIL-STD-810 | MIL-STD-461 | IP67
Dimensions:3.54" X 3.54"90mm X 90mm
Operating Temp.:-45°C to 85°C

The MILTECH 9128 is a 24 triple-speed (10/100/1000Mbps) Copper ports and 4 x 10G Fiber ports embedded Ethernet switch/router supporting both Layer 2 Ethernet switching and full Layer 3 dynamic routing on a single PCB-level solution.

Custom Designed Solutions

For all your requirements, we’ll custom design a solution to fit your needs

Standard Configurations
Model Description
1-9128-000 PCB Level Ethernet Gigabit Switch, 24 x 10/100/1000TX + 4 x 10G ports
MILTECH 9128 Additional configurations available
The 9128 PCB-level Ethernet switch helps simplify the complex traffic management of military-based advanced optics applications. With conformal coating and a wide temperature range, it is ideal for rugged manned and unmanned military and civilian mobile, tactical, airborne vehicle platforms in situational awareness operations.

Advanced network routing features include support for virtual LANS (VLANS), traffic prioritization (QoS), bandwidth aggregation, dynamic routing (RIPV1, V2, OSPF V2/V3, Multicast Routing, VRRP, ECMP Routing) and full IPv6. The MILTECH 9128 is only 3.55” (90mm) by 3.55” (90mm) for easy placement in embedded and OEM platforms.It operates at 3.3VDC with a maximum power consumption of 25 watts.

It has an available Rapid Evaluation Board which allows developers to become familiar with the switching functionality of the product and quickly evaluate the product while accelerating the product design of the final system. This reduces time-to-market, reduces development costs and lowers design risks.
Tailored Products to Meet Your Requirements

Modified Off The Shelf Solutions

All of our products can be configured to your specific requirements. Customers are invited to work with a design engineer to define the output, input range, protection limits and dimensions of the power solution which best meets their project needs. This can frequently be accomplished without NRE. Use the contact form to submit a request, or contact us to discuss your requirements. For our US team call (603) 267-8865, for our European team call: +41-41-740-4554. Configurations created for specific requirements will be assigned a new variant part number.
